| Processor | CPU | SkyLake/KabyLake(R) U-series Core CPU |
| CPU Package | BGA On Board |
| Chipset | SOC |
| BIOS | System BIOS: SPI BIOS |
| Memory | Architecture | Dual channel DDR3L |
| Capacity | Max. 32GB |
| Socket | 2*DDR3L SODIMM |
| Display | Graphic Controller | Intel integrated graphic card |
| VGA | Max. resolution: 2K@60Hz |
| DVI | Max. resolution: 4K@60Hz |
| Dual Display | VGA+DVI Synch. or asynch. Display |
| Ethernet | Controller | LAN 1:Intel I211 GbE LAN（Optional POE） |
| LAN 2:Intel I211 GbE LAN（Optional POE） |
| Super I/O | Controller | NT6106,support system temp. monitoring |
| Watch Dog Timer | 0-255 sec., providing Watch Dog program |
| Audio | Controller | Realtek HD ALC662 audio decoder (right & left channel + MIC) |
| I/O | USB 3.0 | 10 x USB 3.0/2.0 PORT |
| USB 2.0 | 2 x USB 2.0 PORT |
| Serial Port | Com1 9-wire RS232 TX/RX signal, support 4000V surge protection, DB9 port |
| Com2 3-wire RS232 TX/RX signal, support 4000V surge protection, DB9 port |
Com3-COM4 3-wire RS232/RS485(optional),RS232 TX/RX signal, support 4000V surge protection, RS485 support 3KV isolation protection, DB9 port |
| COM5-COM6 3-wire RS232TX/RX signal, support 4000V surge protection, DB9 port |
| GPIO | DB15 male,12bit,program available,freely-defined I/O,3.3V@24mA |
Expansion
Bus | Mini-PCIe | 1* full-size Mini-PCIe socket, support PCIe & USB devices |
| UIM Scoket | 3G UIM Card socket |
| Storage | SATA | 1*standard 7Pin SATA-III& power connector,trasmission rate:max.3Gb/s |
| M-SATA | 1*full-size Mini-PCIe socket, support m-SATA SSD,trasmission rate:max.3Gb/s |
| Power | Power Type | AT/ATX(optional),DC9-30V extended voltage input,
support power reverse & over-voltage protection. |
| Power Consumption | Support max.50W（Including POE） |
| Other | POWER LED/HDD LED |
| POWER BUTTOM |
| Environment | Operating Temp. | -20°C ~ 60°C |
| Storage Temp. | -40°C ~ 80°C |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| Storage Humidity | 0% ~ 90% relative humidity, non-condensing |
| Formfactor | Dimensions | 215 x 136 x 60mm |
| Weight |
| Certificate | FCC, CE, RoHS |
