| Product Features | LCD Screen | 17" TFT LCD, Resolution: 1280×1024 |
| Motherboard | Embedded low power motherboard, 1.6G Hz Dual core |
| RAM | DDR3 2GB |
| Storage | 16GB SSD (up to 64GB) |
| I/O | 3×RS-232,1×RS-232/485(default),2×USB2.0,2×GigaLAN,1×VGA |
| LCD Specification | Display Type | 17" TFT LCD Screen |
| Resolution | 1280×1024 |
| Brightness | 350cd/m² |
| Operating Temp. | 0℃~50℃ |
| LCD Life-span | 50,000 hrs |
| Backlight Life-span | 30,000 hrs |
| Touch Screen Specification | Type | Resistive |
| Tapping Durability | 250g force, >106 times |
| Pensliding Durability | 250g force, >105 times |
| Control | Touch delay time <10ms, half-sine |
| Product Specification | Architecture | Full-closed metal architecture |
| Color | fluorocarbon coating matt frosted black panel,fluorocarbon coating matt silver-gray casing |
| Installation | Embedded |
| Power | 9~30V DC |
| Dimensions | 438×352×53mm |
| Cabinet Mounting-hole | 422×336mm |
| Network | 5.5Kg |
| Environment | Operating Temp. | 0℃~50℃ |
| Operating Humidity | 5%~90%@50℃ |
| Storage Temp. | -20℃~70℃ |
| Storage Humidity | 8%~90%@40℃
|
| Vibration | 10~57Hz,displacement amplitude:0.075mm,57~150Hz, 9.8m/s² |
| Shock | 150m/s² |
| Impact of Pulse Width | 10ms, half-sine |
| Software | OS | WindowsXP、WindowsXPE、Windows7 |
| Application Software | Free bundling HMIBuilder universal version 150-point distributed industrial configuration software |
